Model:

STARMEX SYSTEM 4 AIRCON (9K x3 + 24K) & FREE INSTALLATION

$4,699.00 $5,499.00
Premium installation for HDB New Installation
Key Features
  • Outdoor Unit: MXY-4H33VG
  • Indoor Unit: MSXY-FP10VG x3 + MSXY-FP24VG
  • Warranty: 1 year parts, 5 years on compressor
Premium Installation Package (Applicable for NEW HDB Installation only)

Installation with 0.5 inch CLASS "0" K-FLEX Insulation (Top grade pipe insulator)

Installation with Grade SWG 23 (0.71mm) copper piping (Thick wall copper pipes)

Installation with uPVC 16mm drainage pipe

Dismantle & dispose old air-con system

1 year workmanship installation warranty

Aircon Disclaimer

For aircon installation, it will be installed within 3-4 weeks depending on our slot availabilty.

Price stated applies to Standard HDB (Residential) basic installation ONLY, with the standard piping length given. Additional charge applies for longer pipe run.

Price excludes Stainless-Steel Bracket & PowerPoint.

Additional charges apply for private properties, condos & commercial houses due to the size of the house/building & complications of pipe run.

Any other additional work services such as cutting & patching of false ceiling etc are chargeable.

Notice

We try our best to provide accurate product information from the manufacturer's or agent's website. However, the information on this page may change without notice, and it may not be accurate if there are specification changes. We recommend checking the manufacturer's site for the latest specs and information.

-

While all items available for online purchase can be added to your cart, we cannot guarantee their availability at the time of order processing.

In case we are unable to fulfill your order, we will get in touch with you to provide an alternative option or arrange a full refund.

-

If your product is eligible for warranty, you can find its registration link here.

Installation

SYSTEM 4 (9,000 x3 & 24,000 BTU)

The New Starmex series range is designed to achieve industry’s leading seasonal energy efficiency through use of new technologies and high-performance compressor.

FP Series

LOW STANDBY POWER

Electrical devices consume standby power even when they are not in actual use. While we obviously strive to reduce power consumption during actual use, reducing this wasted power that cannot be seen is also very important.

EASY CLEAN DESIGN

The easily detachable panel is a snap to wash and the airflow vents can be opened without any special tools for quick cleaning of the inside of the air conditioner. It is recommended that the air conditioner can be cleaned regularly as this will increase both operating efficiency and energy-savings. Always clean the heat exchanger, fan and air vent to ensure proper performance and economical operation. It reduces your electricity bill by approx. 45%*.

*Electricity bill comparison of operation under fixed temperature with 8 grams of soil on the fan and one without. Based on internal company data. **Cleaning of filter and heat exchanger is possible by moving the panel.

DUAL BARRIER COATING

It prevent dust and greasy dirt from sticking onto the coated air conditioner. Dirt is generally classified into two groups; hydrophilic dirt such as fiber dust and sand dust, and hydrophobic dirt such as oil and cigarette smoke. Mitsubishi Electric's unique dual barrier coating prevents both hydrophilic and hydrophobic dirt from sticking onto the air conditioner. This dual coating on the inner surface keeps air conditioner clean all year and improves energy efficiency while delivering comfortable clean air.

BENEFITS OF R32 GAS

LOW IN GWP VALUE

Refrigerant has been a debatable topic as a contribution factor that harm the ozone layer. R32 gas - a environmentally friendly and energy efficient refrigerant offers a new alternative. Having a low GWP value of only 677, its 2/3 of the GWP value that R410A carries, decreasing the harm by 30%

REQUIRES LESS REGRIGERANT VOLUME

Due to its lower in density, R32 air conditioning systems use up to 15-20% less refrigerant than R410A equivalents making them more efficient which means lower carbon emissions and lower energy costs with the same effect.

SINGLE COMPONENET OF GAS

R32 is a single compound, CH2F2 unlike R410A which is a mixture of difluoromethane and pentafluoroethane. Being a single component gas, R32 gas is more convenient to work with and easier to recycle as compared to R410A gas. This will result in smaller footprints of the compressors with the same capacity

HIGHER EFFICIENCY

R32 gas has a higher cooling capacity due to its higher in critical temperature, 78.11°C. This results in higher efficiency and higher COP in the R32 gas system. In return, it approximately saves 10% of the electricity bill than R410A gas.

SPECIFICATIONS

MODEL - INDOOR UNIT MSXY-FP10VG MSXY-FP24VG
Rated Capacity 2.8 W 7.1 kW
Power Input 0.028 kW
0.059 kW
Running Current 0.27 A 0.52 A
Airflow Rate 4.1-5.1-6.3-9.1-12.9 CMM (m³/min) 9.3-11.1-13.7-16.1-20.0 CMM (m³/min)
Sound Level * 19-24-29-36-45 dB(A) 30-35-41-45-50 dB(A)
Dimension (W X D X H ) 799 x 232 x 290 mm 923 x 250 x 305 mm
Net Weight 9 kg 13 kg
External Piping Diameter Gas (ø): 9.52 mm
Liquid (ø): 6.35 mm
Gas (ø): 12.7 mm
Liquid (ø): 6.35 mm
MODEL - OUTDOOR UNIT MXY-4H33VG
Capacity (Min - Max) 6.9 (1.3 - 10.7) kW
Power Input 1.42 kW
Full load COP 4.86
Weighted COP ** 5.76
Starting Current 6.37 A
Running Current 6.37 A
Airflow 38.7 CMM (m³/min)
Dimension (W X D X H) 840 x 330 x 710
Net Weight 55 kg
Outdoor Sound Level * 49 dbA
Connection Method Flared
External Piping Diameter Gas (ø): 1 no X 12.7 + 3 no X 9.52
Liquid (ø): 4 no X 6.35
Piping Length Max Length (Each): 25 m
Max. Length: 60 m
Max. Height: 15 m
Refrigerant R32
No. of connectable indoor units (System) 230, 1, 50

*Note: Sound level is measured in anechoic chambers
** Tested based on NEA energy labelling scheme.
